What models of plate and tube integrated laser cutting machines are available for selection?

In modern manufacturing,plate and tube integrated laser cutting machines have become a key equipment for improving production efficiency and product quality in many industries due to their unique advantage of integrating the cutting functions of sheet and pipe materials.Different models of plate and tube integrated laser cutting machines have differences in power,processing range,cutting ability,etc.The following provides a detailed introduction to common optional models.

1.Common models classified by power

（1）Low power models(1000W-2000W)
This type of plate and tube integrated laser cutting machine is suitable for scenarios that require high cutting accuracy but relatively thin material thickness.For example,in some electronic component manufacturing enterprises,it is commonly used to cut thin metal sheets and fine pipes.Its advantage lies in low energy consumption and relatively low operating costs.Taking the 1500W model of a certain brand as an example,it can accurately cut stainless steel plates of 0.5-5mm and stainless steel pipes of 0.5-3mm,with a cutting accuracy of±0.03mm.This model of equipment has a relatively small volume and occupies a small area,making it suitable for processing workshops with limited space.However,due to power limitations,the speed will significantly decrease when cutting thicker materials.
（2）Medium power models(3000W-6000W)
Medium power plate and tube integrated laser cutting machine is a widely used type in the market.It balances cutting efficiency and cutting capability,meeting the needs of most conventional manufacturing industries.For example,the 3000W model can cut carbon steel plates ranging from 0.5-12mm and stainless steel plates ranging from 0.5-5mm.For cutting square and round pipes,the diameter range can reach□2020-□100100mm,andΦ20-Φ150mm.The 6000W model further enhances its cutting capability,capable of handling thicker materials and cutting faster.This type of equipment is widely used in industries such as automotive parts manufacturing and mechanical processing,and its cost-effectiveness is relatively high.It can ensure a certain cutting quality without significantly increasing costs due to excessive power.
（3）High power models(8000W and above)

High power plate and tube integrated laser cutting machines are mainly designed for cutting thick plates and large pipes.In fields such as shipbuilding and large-scale steel structure processing,it is necessary to cut thick metal sheets and pipes,and high-power models can leverage their advantages.For example,the 12000W model can easily cut carbon steel plates of 20mm or more and stainless steel pipes of 10mm or more,with fast cutting speed and good cutting quality.However,high power means higher equipment costs and energy consumption,as well as higher technical requirements for operators.Professional training and rich experience are needed to ensure the safe operation and efficient cutting of equipment.

2.Common models classified by processing format

（1）Small processing format models(3015,4015)
The 3015 model indicates a processing area of 3000mm×1500mm,while the 4015 model has a processing area of 4000mm×1500mm.These small plate and tube integrated laser cutting machines are suitable for processing small-sized parts and are commonly used in industries such as electronic product manufacturing and small mechanical processing.They have the characteristics of small footprint and flexible mobility,and can quickly complete small batch and multi variety processing tasks.Although the processing area is limited,it is not inferior in cutting accuracy and speed,and can meet the production needs with high requirements for part size accuracy.
（2）Medium sized processing format models(4020,6020)
The 4020 model has a processing area of 4000mm×2000mm,while the 6020 model has a processing area of 6000mm×2000mm.Laser cutting machines with medium-sized processing areas have a wider range of applications and can meet the processing needs of most conventional manufacturing industries.In industries such as automobile manufacturing and furniture manufacturing,it is possible to simultaneously process large-sized boards and pipes to improve production efficiency.This type of equipment performs well in terms of stability and cutting quality,and is the preferred model for many enterprises.
（3）Large processing format models(6025,8025)

The processing size of the 6025 model is 6000mm×2500mm,and the processing size of the 8025 model is 8000mm×2500mm.Laser cutting machines with large processing sizes are mainly used for processing large workpieces,such as shipbuilding,large building steel structures,and other fields.They can cut larger materials at once,reduce splicing processes,and improve the overall quality and stability of the product.However,large equipment has high requirements for the load-bearing capacity and space of the factory building,and the equipment price is relatively expensive.

3.Other special models

（1）Dual platform plate and tube integrated laser cutting machine
The dual platform design is a major highlight of this special model.It has two independent processing platforms,which can achieve simultaneous or alternating processing of sheet and pipe materials.When one platform performs cutting operations,another platform can perform loading and unloading operations,greatly improving equipment utilization and production efficiency.This model is suitable for enterprises that require extremely high production efficiency,which can shorten the production cycle and reduce production costs.
（2）Full protection plate and tube integrated laser cutting machine
Full protection design focuses on the safety of operators.The equipment is equipped with comprehensive protective devices,such as shields and safety light curtains,which can effectively prevent laser radiation and splashes generated by cutting from causing harm to personnel.At the same time,the fully protected design can also reduce the impact of external environment on the cutting process,improve cutting quality and stability.In some industries with strict safety requirements,such as aerospace manufacturing,fully protected plate and tube integrated laser cutting machines have been widely used.
There are various models of plate and tube integrated laser cutting machines,and enterprises should consider their own production needs,the characteristics of processing materials,budget,and other factors when choosing.Only by choosing the appropriate model can the advantages of plate and tube integrated laser cutting machines be fully utilized,and the production efficiency and competitiveness of enterprises be improved.
