How to Choose the Right CNC Bending Machine for You

We are a professional bending machine manufacturer with over 10 years of industry experience. Today, we would like to introduce you to how to pick a bending machine:

A bending machine is a machine capable of bending thin plates. They are categorized as manual bending machines, hydraulic bending machines and CNC bending machines.

Before picking a bending machine, it is best to carefully consider what type of bending machine to buy. Picking a machine is not an easy task, the responsibility is not trivial, once you make a poor choice, your production costs will climb and the bending machine will not be expected to pay for itself.

As a user of the equipment in the purchase of bending machine, the main thing is to purchase a bending machine and economic and practical, this need to consider a number of factors, the most important point is to start from their own actual situation.

1. Professional selection methods

First of all, here are two common sense to tell you, the first common sense, if it is a shorter bending machine, then it is better to be able to pad some shims, so that it can better make qualified parts. At the same time this can also shorten the time and increase production. The second common sense, if the application of free bending, in general, this time the bending radius of 0.156 times, it should be noted that the free bending mold is usually applied to a new bending machine, generally produce less than 2 degrees of spring angle.

In addition, extra attention should be paid to the issue of bending degree, which can directly affect the production of the problem, for example: if the bending degree required in the greater than 1 or less than 1 between, then you should use CNC bending machine.

Molds should also pay attention to the conventional molds and their deviation range must pay attention to reduce, generally in the 0.001 inches or so, can not be too large, if it is a fine grinding molds, is in the 0.0004 inches or so of deviation.

All of the above is about the bending machine selection aspects of the introduction, can be said to be more complex.

2. Simple selection method

If you don't know about this, you can provide the manufacturer with the plate material, plate width and plate thickness, and the manufacturer will recommend a suitable bending machine model for you.

Here to tell you, you need to consider the following factors when choosing and buying a suitable CNC bending machine:

(1) According to the metal sheet material to be processed bending, plate thickness, to calculate the need to buy how many tons of CNC bending machine, where the tonnage refers to the maximum pressure of the bending machine, rather than CNC bending machine weight;

(2) The width of the bending machine cutter face (according to the width of the plate to determine), the depth of the throat and the distance between the columns;

(3) Is the choice of electro-hydraulic synchronous CNC bending machine or torsion axis synchronous bending machine is also a matter of consideration, electro-hydraulic synchronous type of bending machine can be more intelligent and fully automated, but the price is higher, the torsion axis synchronous type of bending machine is cheaper;

(4) Electro-hydraulic synchronous bending machine selection type is more, can be customized according to the requirements of the processing workpiece, such as the number of axes required, the type of compensation, laser testing, safety and security.

If you are interested in bending machine, please contact us.
