What is the function of plate rolling machine?

The plate rolling machine is a widely used equipment in industrial production, which is mainly used for bending and rolling treatment of metal plates. Its appearance greatly improves the production efficiency, reduces the labor intensity of workers, and makes an important contribution to the development of modern industry.

As a professional manufacturer of plate rolling machine with ten years of manufacturing experience, we now analyze the plate rolling machine for you in detail to help you better understand and buy this type of equipment.

1.Definition of plate rolling machine

Plate rolling machine is a kind of industrial special metal forming equipment, which is mainly used to roll flat metal sheets or strips into certain cylinders or coils by rolling and bending, so as to facilitate storage, transportation and further processing. Rolling machine is widely used in iron and steel, non-ferrous metals, construction materials, machinery manufacturing and other industries, is an important and indispensable machinery in the modern manufacturing industry.

2. The working principle of the plate rolling machine

The working principle of the plate rolling machine is mainly through the relative movement of its upper and lower rollers, the metal plate placed between them to exert pressure, so that it produces plastic deformation. In the rolling process, the upper roller is usually used as the active roller, the lower roller as the driven roller, by adjusting the gap between the upper roller and the lower roller and the rotating speed of the roller, you can control the degree of bending of the metal plate and the effect of rolling.

3.The main components of the plate rolling machine

In order to ensure stable and efficient operation, the plate rolling machine usually consists of the following key components:

(1) upper and lower rolls: an important part of the plate rolling machine, usually using high-strength forged carbon steel.

(2) Frame: There are one frame each for left and right, and the frame is equipped with lower roller bearings. Inside the frame, there is a square-buckle screw, the upper end of the screw is hinged with the upper roller bearing seat at both ends. In its lower part is equipped with worm gear and spiral vice. The nut in the worm wheel rotates to make the upper roller up or down.

(3) Reducer: installed on the base, through the rotation device to control the rotation speed of the rollers, to ensure that the rolling process is smooth.

(4) Unloading device: mounted on the side of the reducer is used to balance the upper roller when unloading; unloading and recovery is completed by the cylinder.

(5) Base: welded by steel and steel plate. The frame, reducer, motor and so on are mounted on it to ensure the stability of the overall operation.

(6) Electrical control part: centrally installed in the operation box, easy to manipulate and adjust, some high-end models support CNC system, further operation convenience and precision.

4. Functions of plate rolling machine

(1) Sheet molding: through the rotation and pressure of the work rollers, the plate rolling machine can bend the metal sheet into various required shapes, such as cylindrical, conical, oval, curved and so on. To meet different production requirements.

(2) Flat sheet: the plate rolling machine can stretch and press the metal sheet through the synergistic action of multiple rolls to make the surface of the sheet more flat and smooth.

(3) High processing precision: the plate rolling machine utilizes advanced automation control technology to control parameters such as the position, angle and rotational speed of each roll, in order to ensure the precision and consistency of the size of the metal sheet during the rolling process.

(4) Wide range of application: the plate rolling machine can be adapted to the processing needs of metal plates of different materials, thicknesses and widths. By adjusting the work roller spacing, pressure and speed and other parameters, you can realize the processing of different specifications of the sheet.

5.Application Scenarios of Plate Rolling Machine

Plate rolling machine is extremely widely used in the industrial field because of its versatility and high efficiency:

(1) Construction field: Rolling machine can process steel plate molding for main beams, columns, bridges and other components in the building structure.

(2) the field of mechanical processing: plate rolling machine can be used to make cars, trains, airplanes and other machinery and equipment parts.

(3) Power field: the plate rolling machine can be processed and molded for power transformers, coils and other equipment in the core material.

(4) Other fields: the plate rolling machine can also be used in metal furniture, environmental protection equipment, black iron processing field.

In short, plate rolling machine is a very practical machine and equipment, in different fields play an important role. Choosing the right plate rolling machine can not only significantly improve production efficiency, but also ensure product quality and consistency. If you are looking for a plate rolling machine that meets your needs, please feel free to contact us and we will recommend the right machine and give you a quote.
